Featured
Graphite Electrode / UHP
UHP Graphite Electrode
High-current graphite electrode for ultra-high-power EAF steelmaking.
View specifications +Core product system
Graphite electrodes & carbon additives
Explore electrode grades, matched nipples and carbon additives, then request a specification-based quotation for your furnace and process.
Featured
Featured
Graphite Electrode / HP
HP Graphite Electrode
Balanced conductivity and strength for high-power EAF and ladle furnaces.
View specifications +
Featured
Graphite Electrode / RP
RP Graphite Electrode
Dependable, economical electrode for standard-power furnace operation.
View specifications +
Featured
Graphite Electrode / Graphite Electrode Nipples
Graphite Electrode Nipple
Precision-machined 3TPI and 4TPI connections for stable current transfer.
View specifications +Grade selection
Choose around the actual furnace load.
This comparison is an initial selection guide. Final grade, dimensions and properties are confirmed after furnace-data review.
GradeTypical furnaceLoad levelDiameter reference
UHPUltra-high-power EAFVery high current density300-800 mm
HPHigh-power EAF / LFHigh load200-700 mm
RPStandard-power electric / alloy furnaceStandard load75-800 mm
NippleMatched to electrode and socket3TPI / 4TPIBy electrode diameter
Standard size reference
Common dimensions for technical inquiry.
Special specifications can be discussed. Diameter tolerance, length tolerance, socket dimensions and nipple designation are confirmed in the order specification.
- Nominal diameter
- 75 / 100 / 130 / 150 / 200 / 250 / 300 / 350 / 400 / 450 / 500 / 550 / 600 / 650 / 700 / 800 mm
- Common length
- 1600 / 1800 / 2100 / 2400 / 2700 / 2800 mm
- Thread systems
- 3TPI (8.467 mm) / 4TPI (6.350 mm)
- Custom options
- Grade, size, nipple designation, marking and export packing
